Holden V8 304 355 Intake Inlet Manifold, Single Plane High Rise Victor JR. Fits VN EFI Cylinder Heads

Edelbrock ED2894 Holden 304 355 Intake manifold, Carby type Single Plane Hi Rise Intake Manifold, Victor JR. Victor Jr Holden Intake Manifold Single Plane 355+ stroker 4150 Carburetor Flange.

Edelbrock ED2894 Specifications:

• Fits: Holden 304 EFI/VN type cylinder heads (will not suit early 308 carby heads)
• Intake Type: Carburettor Sinlge Plane, High Rise.
• Edelbrock Series: Victor
• RPM Range:  3500-7500 rpm
• EFI Provisions:  Has the flat pads for EFI injector provisoins, these will need to be machined if required. Click the link to See Edelbrock ED3504 Fuel rail kit
• Application: High Performance, high rpm Holden 304 & 355 Stroker engines with larger camshafts over 240 deg @ 050"
• Alternative manifold with EFI injecotor holes - click this link for the Edelbrock ED28945 EFI manifold

Edelbrock ED2894 Victor Jr. 304 Holden intake manifold is for use with competition 355+ stroker motors. This Edelbrock High Rise Single Plane intake manifold suits the Holden V8 engines that utilize the 1988-98 Holden VN cylinder heads. This Holden 308 V8 intake manifold is a single-plane design that is tuned for maximum air flow from 3500 to 7500 rpm. It features a taller design & long tapered runners for a broad operating rpm range in the 304 Holden Stroker V8's. Will fit both stock 1988-1998 EFI style cylinder heads and the Edelbrock Holden VN RPM cylinder heads. This Edelbrock 2894 manifold also features a 4150 flange for use with square-bore carburetors and throttle bodies. Includes extra material for porters to modify for use with 4500 series applications. The water outlet is machined for use with a small-block Chevy Thermostat housing/ waterneck.
