Proline Dual Valve Springs, High RPM Hydraulic Roller 155 lbs@1.900" 415 lbs/in - Chevy BBC 454 & 351C Cleveland Hydraulic Roller (Polished)

SKU: DRP-9415P-16

Proline Dual Valve Springs, High RPM Hydraulic Roller 155 lbs@1.900" 415 lbs/in - Chevy BBC 454 & 351C Cleveland Hydraulic Roller (Polished)

351C & BBC Hydraulic Roller Valve Springs - High RPM

$454.58

or 4 payments of $113.64 with Info

IN STOCK FREE SHIPPING

*FREE SHIPPING ON ORDERS OVER $200!

Description

DRP High RPM Polished Dual Valve Springs. 351C & BBC 454 Hydraulic Roller

Race/Endurance high performance series by PAC Springs.

Polished LS small OD, light weight Hydraulic Roller Dual Valve Springs.

fits Big Block Chevy 454 & 351 Cleveland

Installed Height: 1.900" or 1.800"

Closed / Seat Load: 155lbs @ 1.900" / 176lbs @ 1.850" / 200lbs@1.800"

Spring Rate: 415 lbs

Max Lift: @1.900" .700" @ 060" safety.

@1.800" .620" @ 060" safety.

Valve Spring OD: 1.312"

Valve Spring ID: 0.694"

MADE IN U.S.A BY PAC SPRINGS.

Spring Height Inch	Load lbs
1.950	134
1.900	155
1.850	176
1.800	197
1.750	217
1.700	238
1.650	259
1.600	280
1.550	300
1.500	321
1.450	342
1.400	363
1.350	383
1.300	404
1.250	425
1.200	446
1.150	467
1.122	Coil Bind

Specifications

SKU	DRP-9415P-16
Barcode #	036584270461
Brand	DRP
Seat Height	1.85
Damper	Yes
Seat Pressure	158
Outer Spring Outside Diameter	1.55
Outer Spring Inside Diameter	1.14
Number Of Springs	2
Inner Spring Inside Diameter	0.74
Valve Spring Series	Race Endurance
Coil Bind Height	1.16
Spring Rate	439
