SKU: 20540TBS2LUN

LS1 LS2 Cathedral Port Stage 2 Camshaft. 226/231 LSA 113 Hydraulic Roller Camshaft - Black Magic

RPM Operating Range: 2200-6800

$574.20

or 4 payments of $143.55 with Info

SOLD OUT

Description

Lunati Camshaft, suits 5.7L & 6.0L Cathedral Port, Good street/strip camshaft with wide range. Must have substantial airflow upgrades, inlet and exhaust.

Hydraulic Roller Camshaft.

Fair idle, strong bottom and mid range,works with small nitrous kit or up to 8 psi of boost from a Turbo or Blower.

Lunati's Black Magic series offers incredible power at a great price that won't break the bank. These proven lobe designs ensure reliability while still making great power and sound. Lunati's in-house all black surface finish adds durability, hardness and surface area to the cams, as well as a unique and awesome look. The finish remains intact after initial break-in and aids in identifying the "surface ride" area of the cam while the cam "stages" simplify the selection process for your specific performance goals. Black Magic Camshafts are an excellent choice for a wide range of GM LS performance applications. Only "black magic" can provide this kind of power at this price

Advertised Duration (Int/Exh): 281/286

Duration @ .050 (Int/Exh): 226/231

Gross Valve Lift (Int/Exh): .605"/.598"

LSA:  113

ICL: 109

RPM Range: 2200-6800

Specifications

SKU 20540TBS2LUN
Brand LUNATI
Lifter Type Hydraulic Roller
Cam Type Hydraulic Roller
Camshaft Series LSR Cathedral Port Small Displacement/Max Torque
Basic Operating Rpm Range 1,900-7,000
Lifters Included No
Valve Springs Required Yes
Camshaft Gear Attachment 3-Bolt
Camshaft Material Billet Steel

Reviews

Be The First To Review This Product!

Help other Total Performance users shop smarter by writing reviews for products you have purchased.

Write a product review
