Ford C4 C10 10" Torque Converter fits Cleveland C4 Pan Fill Hi stall Super Street Fighter 26 spline, C4 3500 Stall Converter

TCI 451922 Super StreetFighter Torque Converter for Ford C4

TCI 451922 is a 10" Super StreetFighter high stall torque converter for later Ford C4 / C10 automatic transmissions. It suits 1970–1979 C4 applications with a 26-spline input, 11.4" bolt circle and dipstick mounted into the transmission pan.

This converter is commonly used behind Ford Cleveland and Windsor street/strip combinations that need a higher launch RPM than a standard converter can provide. It is designed for stronger street cars, drag-style builds and high-performance engines with bigger camshafts, higher compression, improved induction and exhaust upgrades.

The Super StreetFighter range uses the same performance-focused design approach as TCI’s StreetFighter converters, but with a higher stall speed to better suit more serious street/strip vehicles. The higher stall helps bring the engine into its stronger RPM range on launch, improving acceleration where the engine combination needs more converter than stock.
Need to see the whole C4 Converter category? - Press this link

TCI 451922 Quick Fitment Summary:

• Brand: TCI Automotive

• Part Number: 451922

• Transmission: Ford C4 / later C4-C10 style automatic

• Year Range: 1970–1979 C4 applications

• Input Spline: 26-spline

• Bolt Circle: 11.4"

• Converter Diameter: 10"

• Lockup: Non-lockup

• Dipstick Location: Suits applications with dipstick mounted into the transmission pan

• Typical Use: High-performance street/strip Ford V8 builds

Expected Stall Speed

Expected stall speed is approximately 3500–3800 RPM behind small block Ford combinations and approximately 3800–4000 RPM behind higher-torque big block combinations. Actual stall speed will vary depending on engine torque, camshaft, compression, vehicle weight, gearing, tyre size and how the car is used.

Do not choose a high stall converter from the RPM number alone. Converter choice needs to match the full combination. A converter that is too tight will make a larger camshaft lazy off the line. A converter that is too loose can make the car unpleasant on the street. Because apparently drivability still matters, despite what every bloke with a “race car” number plate claims.

TCI 451922 C4 Converter Specs:

• 10" Super StreetFighter high stall torque converter

• Designed for Ford C4 26-spline applications

• 11.4" bolt circle

• Furnace-brazed fins for improved durability

• Needle bearing thrust washers

• Hardened pre-ground hub

• Computer balanced

• Mounting hardware included

• 7/16-20 studs and nuts

• Non-lockup design

Best Suited For

• Ford C4 / C10 street and strip builds

• 351 Cleveland and Ford Windsor performance engines

• Engines with larger hydraulic or solid camshafts

• Higher compression street/strip combinations

• Cars with improved induction, exhaust and rear gearing

• Applications needing stronger launch RPM than a standard converter

Important Fitment Notes

This converter suits 1970–1979 Ford C4 applications with a 26-spline input and 11.4" bolt circle. It is commonly used with the later-model C4 / C10 style transmission setup, including applications where the dipstick enters the transmission pan.

Before ordering, confirm your transmission type, input spline count, bolt circle, flexplate size, dipstick location and converter pilot diameter. Ford C4 fitment can vary, and guessing is a wonderful way to buy the wrong converter twice.

Specifications

• Part Number: TCI 451922

• Series: Super StreetFighter

• Transmission Type: Ford C4

• Years: 1970–1979 C4 applications

• Input Spline Quantity: 26

• Converter Diameter: 10"

• Bolt Circle: 11.4"

• Crank Pilot Diameter: 1.375"

• Lockup Compatible: No

• Anti-Ballooning Plate: No

• Furnace-Brazed: Yes

• Balanced: Yes

• Mounting Hardware Included: Yes

• Mounting Hardware Type: 7/16-20 studs and nuts

• Mounting Hardware Quantity: 4

Need Help Confirming Fitment?

If you are not sure whether TCI 451922 suits your Ford C4, contact Total Performance before ordering. Tell us your transmission type, engine, flexplate, spline count, bolt circle and vehicle combination, and we can help confirm whether this is the right converter for your setup.

Call 1800 351 351 or message us through the website. We have been supplying Ford performance parts since 1979 and can help match the right torque converter to your engine, camshaft, gearing and intended use.
