Commodore VN VG VP VR VS 5.0L 304 EFI cylinder Heads V8 TRI-Y Engine Swap Competition, Holden Extractors Headers
Early Commodore with VN/EFI 304 Heads
Description
PACEMAKER, Headers, Extractors, PH5002, V8 Commodore VN VG VP VR VS 5.0L 304 EFI cylinder heads, Tri-Y 1 3/4"
PH 5002 - Commodore VN-VS (Fitted with 5.0L EFI V8) Engine Swap. Competition Header. TRI-Y Design.
Note: We can have these Ceramic Coated - Silver/Chrome or Satin Black finish.
NOTE: March 2024. These extractors have undergone a significant improvement. Previously, the product had a 2 1/4 spigot outlet, but it now features a 3-inch collector cone with a 4-bolt flange. This upgrade has enhanced the product's performance, allowing it to comfortably handle over 600 horsepower
Now comes with an additional flange & gasket to fit to the exhaust system side.
| Part #: | PH 5002 | ||
| P/Steering: | Yes | Gasket: | DSF 63 |
| Air Con: | Yes | Primary Pipe: | 1¾" (44mm) |
| Oxy Sen: | Yes | Secondary Pipe: | 2" (51mm) |
| E.G.R: | N/A | Outlet: | 3" (76mm) |
| Y Branch: | N/A | Fitting Time: | 2.5 Hrs |
SOLD AS A PAIR
Note:
-
Will fit with both Bosch starter motor
-
Will fit with 6 speed manual
-
Suitable for 5.7 litre / 355 Strokers or supercharged 304 motor
-
Will NOT suit series 3 VS or VT 304 5.0Ltr. Requires modification to bellhousing due to clearance issues.
PACEMAKER EXTRACTORS - PROUDLY AUSTRALIAN MADE
Specifications
| SKU | PH5002 |
| Brand | PACEMAKER |
