LS1 Camshaft XFI RPM HI-LIFT 222/224 LSA 112 0.566"/0.568" Hydraulic Roller Cam for GM LS GEN III/IV VT, VX, VY, VZ SS commodore
RPM Operating Range: 1,800-6,800
or 4 payments of $166.38 with
Info
*FREE SHIPPING ON ORDERS OVER $200!

Description
Comp Cams 54-426-11 Great Street Performance LS1 Camshaft upgrade. Fits LS1 VT, VU, VX, VY SS, HSV V8 Holden Commodore
Great street/strip camshaft for mid-range and high RPM power. More punch off the line and great midrange power. Way better street driving camshaft than the bigger cams that lose out the bottom end torque.
Must be tuned. Best results with headers, exhaust and a 2200 RPM street converter.
Comp Cams 54-426-11 Camshaft Specifications:
- Suits Engine Family: GM LS1 with Cathedral Port Cylinder heads ( LS GEN III/IV 1997-2015)
- RPM Operating Range 1,800-6,800
- Camsahft Type: Hydraulic Roller
- Camshaft Series/ Grind number: XFI RPM Hi-Lift
- Camshaft Gear Attachment: 3-Bolt
- Camshaft Usage: Street/Performance
- Advertised Duration: 275/ 271
- Duration at .050 Inch Lift: 222/ 224
- Valve Lift: 0.566" / 0.568"
- Lobe Separation: 112
Recommended Supporting Parts: - click the links below
- Dual Valve Springs Kit - DRP-8374S-LSKIT - Street Line Series
- Beehive Drop in Valve Springs Comp Cams 26918-16
- Valve Spring Compressor Tool - Comp Cams 5462CPG
- Double Row Timing Chain Set -
- Single Row Timing Chain Set -
- Torque Converter - TCI - 242938 2200 RPM
Specifications
| SKU | 54-426-11 |
| Barcode # | 036584068266 |
| Brand | COMP CAMS |
| intake valve lift | 0.566 |
| Exhaust Valve Lift | 0.568 |
| Lifter Type | Hydraulic Roller |
| Advertised Exhaust Duration | 271 |
| Advertised Intake Duration | 275 |
| Cam Type | Hydraulic Roller |
| Exhaust Duration At .050 Inch Lift | 224 |
| Intake Duration At .050 Inch Lift | 222 |
| Lobe Separation | 112 |
| Camshaft Series | XFI RPM Hi-Lift |
| Grind Number | XR275HR |
| Basic Operating Rpm Range | 1,800-6,800 |
| Lifters Included | No |
| Valve Springs Required | Yes |
| Camshaft Gear Attachment | 3-Bolt |
| Camshaft Material | Billet Steel |
