SKU: 08-466-8

Chevy 350 Vortec,TPI, Marine XFI 218/224 LSA 113 Hydraulic Roller Camshaft OEM SBC Small Block Chevy Roller Blocks 87+

RPM Range: 800-5800

$948.02

or 4 payments of $237.00 with Info

IN STOCK  FREE SHIPPING

*Free shipping on orders over $200


Description

Good torque with exceptional mid-range power for 305 and 350 TPI applications.

Fits: Late model Chevy 305/350 Vortec/TPI blocks with OEM Roller Engines (1 piece rear main seal blocks)

Needs upgraded exhaust and custom tuning.

Great allround camshaft upgrade for punchy mid range power & torque. Has a small, yet noticable idle. Great for the cruiser hot rod, Chevy pick up trucks and ski boats (marine)

Xtreme Fuel Injection (XFI™) -Newest and quickest lobe profiles in the Xtreme family; Provide a terrific increase in performance - Tuned for use in EFI Applications where extra air flow signal through the carburetor is not required (feature wider lobe separation with o loss of responsiveness) - Work well with aftermarket cylinder heads and features high lift to get the most out of improved cylinder head ports like the DRP Chevy Cylidner Heads.

Comp Cams 08-466-8 Fits:  Small Block Chevy 350, Hydraulic roller, OEM roller, suits factory roller blocks with the camshaft thrust plate, most blocks have the 1 piece rear seal.

Camshaft Use:  Street, Cruising, Ski Boat

Basic Operating RPM Range:  800-5,800

Intake Duration at 050 inch Lift:  218

Exhaust Duration at 050 inch Lift:  224

Advertised Intake Duration:  268

Advertised Exhaust Duration:  276

Intake Valve Lift with Factory Rocker Arm Ratio:  0.570 in.

Exhaust Valve Lift with Factory Rocker Arm Ratio:  0.565 in.

Valve Lift with Factory Rocker Arm Ratio:   0.570 int./0.565 exh.

Lobe Separation (degrees):   113

Computer-Controlled Compatible:    Yes

Grind Number:   268XFI HR13

Valve Springs Required:   Yes - Please call depending on your cylinder heads.

Notes:  Requires exhaust upgrade and custom computer tuning.

Specifications

SKU 08-466-8
Barcode # 036584105411
Brand COMP CAMS
intake valve lift 0.57
Exhaust Valve Lift 0.565
Lifter Type Hydraulic Roller
Advertised Exhaust Duration 276
Advertised Intake Duration 268
Cam Type Hydraulic Roller
Exhaust Duration At .050 Inch Lift 224
Intake Duration At .050 Inch Lift 218
Lobe Separation 113
Camshaft Series XFI
Grind Number 268XFI HR-13
Basic Operating Rpm Range 800-5,800
Lifters Included No
Valve Springs Required Yes
Camshaft Gear Attachment 3-Bolt
Camshaft Material Austempered Ductile Iron
